ㅁ 들어가며

 Udemy, certified-kubernetes-administrator-with-practice-tests > Mock test 과정을 정리하였습니다.



git 문제풀이 Solution



1. Take a backup of the etcd cluster and save it to /opt/etcd-backup.db

 ㅇ kube doc: etcd backup 검색 > Backing up an etcd cluster

# kube doc: etcd backup > Backing up an etcd cluster 참조
ETCDCTL_API=3 etcdctl --endpoints $ENDPOINT snapshot save snapshotdb

# etcd snapshot save help 참조
$ ETCDCTL_API=3 etcdctl snapshot save -h
NAME:
        snapshot save - Stores an etcd node backend snapshot to a given file

USAGE:
        etcdctl snapshot save <filename>

GLOBAL OPTIONS:
      --cacert=""                               verify certificates of TLS-enabled secure servers using this CA bundle
      --cert=""                                 identify secure client using this TLS certificate file
      --command-timeout=5s                      timeout for short running command (excluding dial timeout)
      --debug[=false]                           enable client-side debug logging
      --dial-timeout=2s                         dial timeout for client connections
  -d, --discovery-srv=""                        domain name to query for SRV records describing cluster endpoints
      --endpoints=[127.0.0.1:2379]              gRPC endpoints
      --hex[=false]                             print byte strings as hex encoded strings
      --insecure-discovery[=true]               accept insecure SRV records describing cluster endpoints
      --insecure-skip-tls-verify[=false]        skip server certificate verification
      --insecure-transport[=true]               disable transport security for client connections
      --keepalive-time=2s                       keepalive time for client connections
      --keepalive-timeout=6s                    keepalive timeout for client connections
      --key=""                                  identify secure client using this TLS key file
      --user=""                                 username[:password] for authentication (prompt if password is not supplied)
  -w, --write-out="simple"                      set the output format (fields, json, protobuf, simple, table)

# endpoint 확인
$ cat /etc/kubernetes/manifests/etcd.yaml | grep listen
- --listen-client-urls=https://127.0.0.1:2379,https://192.1.71.11:2379

# 인증서 정보 확인
$ cat /etc/kubernetes/manifests/etcd.yaml | grep file
    - --cert-file=/etc/kubernetes/pki/etcd/server.crt
    - --key-file=/etc/kubernetes/pki/etcd/server.key
    - --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt
    - --peer-key-file=/etc/kubernetes/pki/etcd/peer.key
    - --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
    - --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
    seccompProfile:


# 명령문 작성
$ ETCDCTL_API=3 etcdctl --endpoints 127.0.0.1:2379 snapshot save /opt/etcd-backup.db \
 --cacert=/etc/kubernetes/pki/etcd/ca.crt \
 --cert=/etc/kubernetes/pki/etcd/server.crt \
 --key=/etc/kubernetes/pki/etcd/server.key
Snapshot saved at /opt/etcd-backup.db

2. Create a Pod called redis-storage with image: redis:alpine with a Volume of type emptyDir that lasts for the life of the Pod.
 - Pod named 'redis-storage' created
 - Pod 'redis-storage' uses Volume type of emptyDir
 - Pod 'redis-storage' uses volumeMount with mountPath = /data/redis

# 명령문 작성
$ k run redis-storage --image=redis:alpine --dry-run=client -o yaml > redis-storage.yaml
$ cat redis-storage.yaml
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: redis-storage
  name: redis-storage
spec:
  containers:
  - image: redis:alpine
    name: redis-storage
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}


# emptyDir 문법 검색 > (emptyDir configuration example)
  volumes:
  - name: cache-volume
    emptyDir:
      sizeLimit: 500Mi

# redis-storage.yaml 완성
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: redis-storage
  name: redis-storage
spec:
  containers:
  - image: redis:alpine
    name: redis-storage
    resources: {}
    volumeMounts:
    - mountPath: /data/redis
      name: cache-volume
  dnsPolicy: ClusterFirst
  restartPolicy: Always
  volumes:
  - name: cache-volume
    emptyDir: {}
status: {}

# create
$ k create -f redis-storage.yaml
pod/redis-storage created

 ㅇ kube doc 검색: pod volume > emptyDir.  emptyDir configuration example





3. Create a new pod called super-user-pod with image busybox:1.28. Allow the pod to be able to set system_time.
 - The container should sleep for 4800 seconds.

# sample yaml 생성
$ k run super-user-pod --image=busybox:1.28 --dry-run=client -o yaml > super-user-pod.yaml
$ cat super-user-pod.yaml
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: super-user-pod
  name: super-user-pod
spec:
  containers:
  - image: busybox:1.28
    name: super-user-pod
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}


# security 참조 검색. security capability > Set the security context for a Container
apiVersion: v1
kind: Pod
metadata:
  name: security-context-demo-4
spec:
  containers:
  - name: sec-ctx-4
    image: gcr.io/google-samples/node-hello:1.0
    securityContext:
      capabilities:
        add: ["NET_ADMIN", "SYS_TIME"]


# yaml 완성
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: super-user-pod
  name: super-user-pod
spec:
  containers:
  - image: busybox:1.28
    name: super-user-pod
    command: ["sleep", "4800"]
    securityContext:
      capabilities:
        add: ["SYS_TIME"]
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}


# create
$ k create -f super-user-pod.yaml
pod/super-user-pod created

# pod 확인 및 describe에서 command sleep 적용확인

 ㅇ 참조
 - Set capabilities for a Container





4. A pod definition file is created at /root/CKA/use-pv.yaml.
Make use of this manifest file and mount the persistent volume called pv-1.
Ensure the pod is running and the PV is bound.
 - mountPath: /data

# yaml 파일 확인
$ cat  /root/CKA/use-pv.yaml
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: use-pv
  name: use-pv
spec:
  containers:
  - image: nginx
    name: use-pv
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}


# pv 생성 여부 확인
$ k get pv
NAME   CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS      CLAIM   STORAGECLASS   REASON   AGE
pv-1   10Mi       RWO            Retain           Available                                   7m30s


# pvc 생성 여부 확인
$ k get pvc
No resources found in default namespace.


# sample yaml 탐색
# kube doc: pvc > Persistent Volumes > PersistentVolumeClaims 선택
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: myclaim
spec:
  accessModes:
    - ReadWriteOnce
  volumeMode: Filesystem
  resources:
    requests:
      storage: 8Gi


# pvc.yaml 작성
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: my-pvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 10Mi

# create
$ k create -f pvc.yaml
persistentvolumeclaim/my-pvc created


# 확인
$ k get pvc
NAME     STATUS   VOLUME   CAPACITY   ACCESS MODES   STORAGECLASS   AGE
my-pvc   Bound    pv-1     10Mi       RWO                           4s


# Claims As Volumes 참조
apiVersion: v1
kind: Pod
metadata:
  name: mypod
spec:
  containers:
    - name: myfrontend
      image: nginx
      volumeMounts:
      - mountPath: "/var/www/html"
        name: mypd
  volumes:
    - name: mypd
      persistentVolumeClaim:
        claimName: myclaim


# /root/CKA/use-pv.yaml 수정
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: use-pv
  name: use-pv
spec:
  containers:
  - image: nginx
    name: use-pv
    resources: {}
    volumeMounts:
    - mountPath: "/data"
      name: mypd
  volumes:
    - name: mypd
      persistentVolumeClaim:
        claimName: my-pvc
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}

ㅇ 참조

 - Persistent Volumes

 - Claims As Volumes





5. Create a new deployment called nginx-deploy, with image nginx:1.16
and 1 replica. Next upgrade the deployment to version 1.17 using rolling update.

# deployment 생성
$ k create deployment nginx-deploy --image=nginx:1.16 --replicas=1
deployment.apps/nginx-deploy created


# pod 확인
$ k get pod
NAME                            READY   STATUS    RESTARTS   AGE
nginx-deploy-7dc9dd795f-jdf2z   1/1     Running   0          41s


# upgrage 시작
# set image help 참조
$ k set image --help
~~
# Set a deployment's nginx container image to 'nginx:1.9.1', and its busybox container image to 'busybox'
  kubectl set image deployment/nginx busybox=busybox nginx=nginx:1.9.1
~~


# 명령문 작성 및 실행
$ kubectl set image deployment/nginx-deploy nginx=nginx:1.17
deployment.apps/nginx-deploy image updated

# 확인
$ k describe deployments.apps nginx-deploy | grep 1.17
    Image:        nginx:1.17







6. Create a new user called john. Grant him access to the cluster.
John should have permission to create, list, get, update and delete pods in the development namespace .
The private key exists in the location: /root/CKA/john.key  and csr at /root/CKA/john.csr.
 - Important Note: As of kubernetes 1.19, the CertificateSigningRequest object expects a signerName.
 - Please refer the documentation to see an example. The documentation tab is available at the top right of terminal.

# Create a CertificateSigningRequest 참조
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
  name: myuser
spec:
  request: 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
  signerName: kubernetes.io/kube-apiserver-client
  expirationSeconds: 86400  # one day
  usages:
  - client auth


# csr base64 decord
$ cat john.csr | base64 | tr -d "\n"


# john-csr.yaml 완성
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
  name: john-developer
spec:
  request: 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
  signerName: kubernetes.io/kube-apiserver-client
  expirationSeconds: 86400  # one day
  usages:
  - client auth


# create
$ k create -f john-csr.yaml
certificatesigningrequest.certificates.k8s.io/john-developer created


# 확인 및 approve
$ k get csr
NAME             AGE   SIGNERNAME                                    REQUESTOR                  REQUESTEDDURATION   CONDITION
csr-2sktz        85m   kubernetes.io/kube-apiserver-client-kubelet   system:bootstrap:elv81r    <none>              Approved,Issued
csr-8w65f        85m   kubernetes.io/kube-apiserver-client-kubelet   system:node:controlplane   <none>              Approved,Issued
john-developer   66s   kubernetes.io/kube-apiserver-client           kubernetes-admin           24h                 Pending

$ k certificate approve john-developer
certificatesigningrequest.certificates.k8s.io/john-developer approved

ㅇ 참조

 - Create a CertificateSigningRequest



# role 생성과정
# 참조 구문 검색
$ k create role --help
~~
# Create a role named "foo" with SubResource specified
kubectl create role foo --verb=get,list,watch --resource=pods,pods/status
~~


# role 명령문 작성
kubectl create role developer --verb=create,get,list,update,delete --resource=pods -n development


# role 적용확인
$ k describe role -n development developer
Name:         developer
Labels:       <none>
Annotations:  <none>
PolicyRule:
  Resources  Non-Resource URLs  Resource Names  Verbs
  ---------  -----------------  --------------  -----
  pods       []                 []              [create get list update delete]


# Access 권한 확인 시 참조
$ k auth can-i get --help
~~
# Check to see if I can get the job named "bar" in namespace "foo"
kubectl auth can-i list jobs.batch/bar -n foo
~~

# Access 권한 확인
$ k auth can-i get pods -n development --as john
no
$ k auth can-i create pods  -n development --as john
no


# rolebinding help
$ k create rolebinding --help
~~
# Create a role binding for user1, user2, and group1 using the admin cluster role
kubectl create rolebinding admin --clusterrole=admin --user=user1 --user=user2 --group=group1
~~


# rolebinding 작성 및 실행
$ kubectl create rolebinding john-developer --role=developer --user=john -n development
rolebinding.rbac.authorization.k8s.io/john-developer created


# 생성 확인
k get rolebindings.rbac.authorization.k8s.io -n development
NAME             ROLE             AGE
john-developer   Role/developer   31s

# 권한 확인
$ k auth can-i get pods -n development --as john
yes
$ k auth can-i create pods -n development --as john
yes
$ k auth can-i watch pods -n development --as john
no





7. Create a nginx pod called nginx-resolver using image nginx,
expose it internally with a service called nginx-resolver-service.
Test that you are able to look up the service and pod names from within the cluster.
Use the image: busybox:1.28 for dns lookup.
Record results in /root/CKA/nginx.svc and /root/CKA/nginx.pod

# nginx-resolver 생성
$ k run nginx-resolver --image=nginx
pod/nginx-resolver created


# pod 생성확인
$ k get po
NAME             READY   STATUS    RESTARTS   AGE
nginx-resolver   1/1     Running   0          3m6s


# 서비스 연결
$ k expose pod nginx-resolver --name=nginx-resolver-service --port=80
service/nginx-resolver-service exposed


# 서비스 확인
$ k get svc
NAME                     TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)   AGE
kubernetes               ClusterIP   10.96.0.1       <none>        443/TCP   79m
nginx-resolver-service   ClusterIP   10.111.232.12   <none>        80/TCP    68s


# busybox 생성
$ k run busybox --image=busybox:1.28 -- sleep 4000
pod/busybox created


# nslookup 실행
$ k exec busybox -- nslookup nginx-resolver-service > /root/CKA/nginx.svc

$ cat /root/CKA/nginx.svc
Server:    10.96.0.10
Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local

Name:      nginx-resolver-service
Address 1: 10.111.232.12 nginx-resolver-service.default.svc.cluster.local


# pod dns 정보 확인을 위한 IP 체크
$ k get po -o wide
NAME             READY   STATUS    RESTARTS   AGE    IP             NODE     NOMINATED NODE   READINESS GATES
busybox          1/1     Running   0          5m9s   10.244.192.2   node01   <none>           <none>
nginx-resolver   1/1     Running   0          10m    10.244.192.1   node01   <none>           <none>

# DNS 체크
# 참조 doc: Pods A/AAAA records
# 172-17-0-3.default.pod.cluster.local
$ k exec busybox -- nslookup 10-244-192-1.default.pod.cluster.local
Server:    10.96.0.10
Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local

Name:      10-244-192-1.default.pod.cluster.local
Address 1: 10.244.192.1 10-244-192-1.nginx-resolver-service.default.svc.cluster.local


$ k exec busybox -- nslookup 10-244-192-1.default.pod.cluster.local > /root/CKA/nginx.svc

ㅇ 참조 doc : Pods A/AAAA records





8. Create a static pod on node01 called nginx-critical with image nginx
and make sure that it is recreated/restarted automatically in case of a failure.
 - Use /etc/kubernetes/manifests as the Static Pod path for example.

# 참조 yaml 생성
$ kubectl run nginx-critical --image=nginx --restart=Always --dry-run=client -o yaml
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: nginx-critical
  name: nginx-critical
spec:
  containers:
  - image: nginx
    name: nginx-critical
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}


$ cat > /etc/kubernetes/manifests/nginx-critical.yaml
apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: nginx-critical
  name: nginx-critical
spec:
  containers:
  - image: nginx
    name: nginx-critical
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}
^C

$ k get po
NAME                          READY   STATUS    RESTARTS   AGE
busybox                       1/1     Running   0          14m
nginx-critical-controlplane   1/1     Running   0          10s
nginx-resolver                1/1     Running   0          19m
